HTH618C Series-III
Harvester Head
HTH616C Series-III
Harvester Head
HTH624C 4X4 LP
Loader Processor
HTH623C LP
Loader Processor
H212
Harvester Head
H225E
Harvester Head
H270 Series II
Harvester Head
H219
Harvester Head
H219X
Harvester Head
H423
Harvester Head
H425HD
Harvester Head
H425X
Harvester Head
H425
Harvester Head
H424
Harvester Head
HTH622B Series-III
Harvester Head
HTH622C 4X4
Harvester Head
HTH623C
Harvester Head
HTH624C 4X4
Harvester Head
HTH624C
Harvester Head
HTH625C
Harvester Head
HTH626 Series II
Harvester Head
FL100
Felling Head
CH6
Harvester Crane
CH7
Harvester Crane
CH9
Harvester Crane
CH135S
Harvester Crane
CF1
Forwarder Crane
CF5
Forwarder Crane
CF7
Forwarder Crane
CF7S
Forwarder Crane
CF8
Forwarder Crane
TimberRite H‑16
Measuring and Control

When it comes to a high performing thinning head, the agile HTH618C Series-III is perfectly equipped. Its responsive valve and twin lower delimb arms provide superior delimbing in a durable and compact design.

- Net Weight
- 2300 kg / 5,071 lb.

- Max Hydraulic Requirements
- 35 MPa / 5,076 psi

- Max Delimb Opening
- 660 mm / 26 in.

- Max Feed Roller Opening
- 680 mm / 27 in.

- Max Sawing Capacity
- 550 mm / 22 in.

- Carrier Size
- 22-30 metric tons
Featuring a highly efficient valve and extensive optionality, the versatile HTH616C Series-III is performance-ready for productivity on wheeled or tracked carriers.

- From; Without Rotator and Link
- 1800 kg / 3,968 lb.

- From; Without Link; Standard Rotator
- 2000 kg / 4,409 lb.

- Max Hydraulic Requirements
- 35 MPa / 5,076 PSI

- Max Delimb Opening
- 660 mm / 26 in.

- Max Feed Roller Opening*
*Harvesting Knives - 685 mm / 27 in.

- Max Sawing Capacity
- 550 mm / 22 in.

- Carrier Size
- 20+ metric ton

- Carrier Size
- 20-30 metric tons
With four-wheel-drive and a wide body design, the versatile HTH624C 4x4 LP is built for exceptional delimbing, log handling and productivity.

- Net Weight
- 3560 kg / 7,848 lb.

- Max Hydraulic Requirements
- 35 MPa / 5,075 psi

- Max Delimb Opening
- 939 mm / 37 in.

- Max Feed Roller Opening
- 870 mm / 34 in.

- Max Sawing Capacity
- 815 mm / 32 in.

- Carrier Size
- 27+ metric ton
With a large delimb opening plus shorter tilt frame providing improved reach for high deck piles, the HTH623C LP is built to work productively in tight spaces.

- Net Weight
- 3140 kg / 6,923 lb.

- Max Hydraulic Requirements
- 35 MPa / 5,075 psi

- Max Delimb Opening
- 939 mm / 37 in.

- Max Feed Roller Opening
- 875 mm / 34 in.

- Max Sawing Capacity
- 750 mm / 29 in.

- Carrier Size
- 25-34 metric ton
Built for performance and speed, the compact and agile H212 delivers big productivity for harvesting, processing and debarking applications.

- Weight (Without Rotator, Link or Multi-Tree Handling)
- 770 kg / 1,698 lb

- Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 520 mm / 20.5 in

- Delimbing Diameter Tip-to-Tip
- 360 mm / 14.2 in
Specifically designed for single-pass eucalyptus debarking, the powerful, high-capacity H225E harvester head productively dominates in the harsh application.

- Weight (Option dependent, without rotator & link)
- 1,690 kg / 3,726 lb

- Max Hydraulic Requirements
(Option dependent) - 28 Mpa / 4,061 psi
35 MPa / 5,076 psi

- Cutting Capacity
- 550 mm / 21.7 in

- Delimbing Diameter Tip-to-Tip
- 430 mm / 16.9 in
Innovatively designed for superior performance in late-thinning and final-harvest applications, the Waratah H270 Series II high-capacity harvester head comes with a package of improvements designed to work as hard as you.

- Weight (Without Rotator & Link)
- 1,350 kg / 2,976 lb

- Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 650 mm / 25.6 in

- Delimbing Diameter Tip-to-Tip
- 460 mm / 18.1 in
With a high capacity, power and agility, the H219 is ideal for late thinning and regeneration harvesting.

- Weight (without rotator & link)
- 1970 kg / 4,343 lb.

- Max Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 750 mm / 29.5 in.

- Delimbing Diameter Tip-to-Tip
- 510 mm / 20.1 in.
Primarily for tracked carrier applications, the H219X comes standard with a heavy-duty tilt frame for maximum productivity.

- Weight (without rotator & link)
- 2050 kg / 4,519 lb.

- Max Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 750 mm / 29.5 in.

- Delimbing Diameter Tip-to-Tip
- 510 mm / 20.1 in.
The Waratah H423 is designed to carry out a wide range of harvesting jobs from early to late thinnings, to light regeneration harvesting. It has outstanding multi-tree-handling qualities, a compact frame design, and excellent power-to-weight ratios.

- Weight (Without Rotator & Link)
- 955 kg / 2,105 lb

- Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 580 mm / 22.8 in

- Delimbing Diameter Tip-to-Tip
- 420 mm / 16.5 in
The rugged H425HD is built to work on your toughest jobs. A heavy-duty tilt frame, feed motors and guarding provide even more durability.

- Weight (Without Rotator & Link)
- 1390 kg / 3,064 lb.

- Max Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 750 mm / 29.5 in.

- Delimbing Diameter Tip-to-Tip
- 460 mm / 18.1 in.
The H425X harvesting head is purpose-built for tracked harvesters and features a rugged main saw box with heavier steel plating, extra component guarding, hose protection and increased drive arm durability.

- Weight (Without Rotator & Link)
- 1426 kg / 3,143 lb.

- Max Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 750 mm / 29.5 in.

- Delimbing Diameter Tip-to-Tip
- 460 mm / 18.1 in.
The Waratah H425 Harvester Head combines large-time-cutting power with excellent delimbing quality. The H425 is hard to beat when it comes to productivity, uptime, and low daily operating costs..

- Weight (Without Rotator & Link)
- 1360 kg / 2,998 lb.

- Max Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 750 mm / 29.5 in.

- Delimbing Diameter Tip-to-Tip
- 460 mm / 18.1 in.
Characterized by its consistent performance and skill set in second thinnings and early regeneration cuttings, the versatile H424 is equally suited for processing or debarking applications.

- Weight (Without Rotator & Link)
- 1105 kg / 2,436 lb.

- Max Hydraulic Requirements
- 28 MPa / 4,061 psi

- Cutting Capacity
- 620 mm / 24.4 in.

- Delimbing Diameter Tip-to-Tip
- 430 mm / 17.0 in.
The HTH622B Series-III delivers increased productivity, improved feeding and saw performance.

- Net Weight
- 2450 kg / 5,401 lb.

- Max Hydraulic Requirements
- 35 MPa / 5,075 psi

- Max Delimb Opening
- 650 mm / 26 in.

- Max Feed Roller Opening
- 730 mm / 29 in.

- Max Sawing Capacity
- 750 mm / 30 in.

- Carrier Size
- 24-30 metric ton

- Carrier Size
- 20-30 metric tons
Engineered for the toughest conditions, the new four-roller Waratah HTH622C 4x4 multistem processing head delivers the performance and proven innovation you expect from the industry leader.

- Net Weight
- 2760 kg / 6,085 lb.

- Max Hydraulic Pressure
- 35 MPa / 5,076 psi

- Max Delimb Opening
- 650 mm / 26 in.

- Max Feed Roller Opening
- 780 mm / 31 in.

- Max Sawing Capacity
- 750 mm / 30 in.

- Carrier Size
- 25-35 metric ton
The Waratah HTH623C harvester head delivers power, torque and speed. There is a wealth of power, strength and automated systems with this harvesting head.

- Net Weight
- 3040 kg / 6,702 lb.

- Max Hydraulic Pressure
- 35 MPa / 5,076 psi

- Max Delimb Opening
- 700 mm / 28 in.

- Max Feed Roller Opening
- 875 mm / 34 in.

- Max Sawing Capacity
- 750 mm / 30 in.

- Carrier Size
- 25-34 metric ton
Born to perform. With its effortless four wheel drive, and high torque feed motors, the H624C 4X4 provides unyielding delimbing power, and responsive feed speeds.

- Net Weight
- 3560 kg / 7,848 lb.

- Max Hydraulic Pressure
- 35 MPa / 5,076 psi

- Max Delimb Opening
- 710 mm / 28 in.

- Max Feed Roller Opening
- 875 mm / 34 in.

- Max Sawing Capacity
- 815 mm / 32 in.

- Carrier Size
- 27+ metric ton
Proven in medium to large wood harvesting and processing, Waratah's big-timber-tackling HTH624C harvester head can easily handle species such as radiata pine, poplar, and aspen.

- Net Weight
- 3530 kg / 7,782 lb.

- Max Hydraulic Pressure
- 35 MPa / 5,075 psi

- Max Delimb Opening
- 760 mm / 30 in.

- Max Feed Roller Opening
- 850 mm / 34 in.

- Max Sawing Capacity
- 810 mm / 32 in.

- Carrier Size
- 30+ metric ton
The aggressive HTH625C optimizes productivity with impressive log control. This high-performer flies through timber with great log handling with twin lower delimb arms.

- Net Weight
- 4390 kg / 9,678 lb.

- Max Hydraulic Pressure
- 35 MPa / 5,076 psi

- Max Delimb Opening
- 800 mm / 31.5 in.

- Max Feed Roller Opening
- 850 mm / 34 in.

- Max Sawing Capacity
- 900 mm / 35 in.

- Carrier Size
- 35+ metric ton
Go large or go home. Known for its capabilities in extra-large timber - the durable and iconic HTH626 Series II dominates big wood. Period.

- Net Weight
- 4850 kg / 10,692 lb.

- Max Hydraulic Pressure
- 35 MPa / 5,076 psi

- Max Delimb Opening
- 900 mm / 35 in.

- Max Feed Roller Opening
- 980 mm / 39 in.

- Max Sawing Capacity
- 860 mm / 34 in.

- Carrier Size
- 35+ metric ton
Unmatched strength plus versatility. Meet the FL100. This bonafide jack-of-all-trades owns the steepest of slopes and shovels the heaviest of timber, all while getting better logs to the landing. Simply put, it's a beast. And truly Built to Work™.

- Net Weight
- 2995 kg / 6,600 lb

- Hydraulic Requirements
- 35 MPa / 5,076 psi

- Max Grapple Opening
- 1470 mm / 57.8 in

- Maximum Sawing Capacity
- 1000 mm / 39.3 in

- Carrier Size
- 30+ metric ton
Waratah offers versatile, purpose-built harvester, forestry and logging cranes. These cranes are forest-ready, dramatically increase the working zone and provide optimum height and lift capacity.

- CH610 Max. Load
- 1,150 kg / 2,535 lb

- CH610 Outreach
- 10m / 393 in

- CH610 Weight
- 2,300 kg / 5,070 lb
Waratah offers versatile, purpose-built harvester, forestry and logging cranes. These cranes are forest-ready, dramatically increase the working zone and provide optimum height and lift capacity.

- CH786 Max. Load
- 1,750 kg / 3,858 lb

- CH786 Outreach
- 8.6m / 338 in

- CH786 Weight
- 3,050 kg / 6,724 lb
Waratah offers versatile, purpose-built harvester, forestry and logging cranes. These cranes are forest-ready, dramatically increase the working zone and provide optimum height and lift capacity.

- CH9 - 10 Max. Load
- 1690 kg / 3,726 lb.

- CH9 - 10 Outreach
- 10 m / 394 in.

- CH9 - 10 Weight
- 3450 kg / 7,606 lb.
Waratah offers versatile, purpose-built harvester, forestry and logging cranes. These cranes are forest-ready, dramatically increase the working zone and provide optimum height and lift capacity.

- CH135S - 8.3 Max. Load
- 1,230 kg / 2,706 lb

- CH135S - 8.3 Outreach
- 8.6 m / 344 in

- CH135S - 8.3 Weight
- 2,090 kg / 4,598 lb
Waratah offers all-around purpose-built forwarder cranes. These booms increase the ability to work close to the carrier and are forest-ready. They provide optimum height and lift capacity.

- CF172 Max. Load
- 730 kg / 1,609.3 lb

- CF172 Outreach
- 7.2 m / 283 in

- CF172 Weight
- 1,220 kg / 2,689 lb
Waratah offers all-around purpose-built forwarder cranes. These booms increase the ability to work close to the carrier and are forest-ready. They provide optimum height and lift capacity.

- CF572 Max. Load
- 1,080 kg / 2,381 lb

- CF572 Outreach
- 7.2 m / 283 in

- CF572 Weight
- 1,225 kg / 2,700 lb
Waratah offers all-around purpose-built forwarder cranes. These booms increase the ability to work close to the carrier and are forest-ready. They provide optimum height and lift capacity.

- CF772 Max. Load
- 1,390 kg / 3,064 lb

- CF772 Outreach
- 7.2 m / 283 in

- CF772 Weight
- 1,510 kg / 3,329 lb
Waratah offers all-around purpose-built forwarder cranes. These booms increase the ability to work close to the carrier and are forest-ready. They provide optimum height and lift capacity.

- CF772S Max. Load
- 1,400 kg / 3,086 lb

- CF772S Outreach
- 7.2 m / 283 in

- CF772S Weight
- 1,710 kg / 3,769 lb
Waratah offers all-around purpose-built forwarder cranes. These booms increase the ability to work close to the carrier and are forest-ready. They provide optimum height and lift capacity.

- CF873 Max. Load
- 1,650 kg / 3,638 lb

- CF873 Outreach
- 7.3 m / 287 in

- CF873 Weight
- 2,010 kg / 4,431 lb
Waratah's TimberRite is an extraordinarily accurate measuring system that generates versatile operational reports to monitor uptime and productivity.

- Intelligent Control

- Maximum Productivity

- Machine Connectivity

- Mapping

- Real-Time Data
